Ryan Malloy
9ca4da98e8
Multi-record clausal programs are now editable end-to-end. A chain
spans N consecutive slots — head (WHEN/AT/EVERY) + zero-or-more
AND/OR condition records + one-or-more THEN action records — so
"editing" means rewriting the whole run, validating that any
expansion doesn't trample adjacent programs, and clearing any old
slots when the chain shrinks.
H1 — backend:
* programs/get for chains now returns chain_members[] with each
member's slot + role + raw fields. The editor uses this to seed
one editable form-row per slot.
* New programs/chain/write command: takes head_slot + head dict +
conditions[] + actions[], does N sequential download_program
calls, then clears any old chain slots that fell outside the new
range. Validates:
- head_slot + new_len doesn't extend past slot 1500
- any expansion-into slot not already part of THIS chain is FREE
(anti-trample: refuse rather than overwrite an adjacent program)
- at least one THEN action present (empty chain rejected)
Updates coordinator.data.programs immediately so subsequent list
calls reflect the edit before the next poll.
H2 — TS helpers:
* AND-record encoding mirrors compact-form cond family bytes
(0x04 ZONE / 0x08 CTRL / 0x0C TIME / 0x00 OTHER + 0x10+ SEC) but
with a slightly different bit layout: the family byte lives at
fields.cond & 0xFF (disk byte 1) and the instance at
(fields.cond2 >> 8) & 0xFF (disk byte 3). The selector bit is
family's bit 0x02 instead of cond's 0x0200. decodeAndCondition /
encodeAndCondition handle both directions; round-trip exact.
* isStructuredAnd helper detects records with OP > 0 (TEMP > N
comparisons etc.); those render read-only in the chain editor
with a warning banner.
* emptyAndRecord / emptyOrRecord / emptyThenRecord helpers for
the add-condition / add-action buttons.
H3 — chain editor UI:
* New _chainDraft state (parallel to _editingDraft for compact form)
with head + conditions[] + actions[] arrays. Mutation helpers
preserve immutability via array-copy-then-patch.
* "Edit" button on chain detail now opens the chain editor instead
of returning early (previous read-only behaviour).
* Three sub-renderers: trigger section dispatches on prog_type
(WHEN→event-id builder reusing the EVENT helpers, AT→time+days
reusing TIMED layout, EVERY→single seconds input that packs into
cond+cond2), conditions section with per-row add/remove (separate
+ AND IF and + OR IF buttons in the legend), actions section with
per-row add/remove (+ THEN button; at least one action enforced).
* Structured-OP AND records render with an explanatory read-only
banner and a × button to drop the row entirely — preserves the
data when the user doesn't touch it, lets them remove it cleanly
when they want to.
* Each row picks objects via _bucketWithPreserve so out-of-range
zone/unit/area indices stay safe.
5 new HA integration tests:
* get-chain returns chain_members with correct roles + raw fields
* chain/write in-place rewrite preserves footprint, updates bytes
* chain/write shrink clears the trailing old slots
* chain/write refuses to trample an adjacent program on expansion
* chain/write rejects zero-actions submission
Live screenshot 11-chain-editor.png: state injection into the side
panel (real panel has no chains) shows the editor rendering a sample
WHEN zone-state → AND IF unit ON → 2x THEN action chain with every
control populated and functional.
Full suite: 653 passed, 1 skipped (up from 648, 5 new chain tests).
Frontend bundle: 82 KB minified (up from 63 KB).
